DIFFERENTIAL RING AND PINION FOR DANA 30 JK FRONT AND DANA 44 JK REAR - RING AND PINIONS INCLUDING TIMKEN BEARING KITS; FOR JK; 4.88 RATIO; REQUIRES 3.73 AND HIGHER CARRIER; IF CURRENTLY USING A 3.21 RATIO YOU WILL NEED TO PURCHASE A NEW FR
Motive Gear offers some of the toughest drive train components on the market today. If you are looking for the largest line of performance ring and pinion gear options available with gear sets in a wide range of ratios for nearly every application, both on and off-road, check out Motive Gear. Motive Gear products can be found in the winner's circle at racing events worldwide. The superior quality of Motive Gear components is the result of years of racing development, outstanding design and state-of-the-art manufacturing methods. Extensive testing is performed on all products by our in-house engineers.
Motive Gear offers some of the toughest drive train components on the market today. If you are looking for the largest line of performance ring and pinion gear options available with gear sets in a wide range of ratios for nearly every application, both on and off-road, check out Motive Gear. Motive Gear products can be found in the winner's circle at racing events worldwide. The superior quality of Motive Gear components is the result of years of racing development, outstanding design and state-of-the-art manufacturing methods. Extensive testing is performed on all products by our in-house engineers.
- DIFFERENTIAL RING & PINION FOR DANA 30 JK FRONT & DANA 44 JK REAR - RING & PINIONS INCLUDING TIMKEN BEARING KITS
- FOR JK
- 4.88 RATIO
- REQUIRES 3.73 & HIGHER CARRIER
- IF CURRENTLY USING A 3.21 RATIO YOU WILL NEED TO PURCHASE A NEW FRONT CARRIER
Information:
DIFFERENTIAL RING & PINION FOR DANA 30 JK FRONT & DANA 44 JK REAR - RING & PINIONS INCLUDING TIMKEN BEARING KITS; FOR JK; 4.88 RATIO; REQUIRES 3.73 & HIGHER CARRIER; IF CURRENTLY USING A 3.21 RATIO YOU WILL NEED TO PURCHASE A NEW FRONT CARRIERApplication Summary:
| Year | Make/Model |
|---|---|
| 2007-2018 | Jeep Wrangler |
This item is a package with the following components:
| Attributes | |
| App/Model | Dana 30 JK Reverse, Dana 44 JK |
| Axle Type | Dana 30, Dana 44 |
| California Proposition 65 | WARNING: Cancer - www.P65Warnings.ca.gov |
| Country of Origin (Primary) | US |
| Cover Bolt Quantity | 10, 10 |
| Differential Carrier Break | Front Open Carrier 3.73 Ratio and Higher (D30-488RJK) |
| Differential Case Design Type | Dana 30 Front (D30-488RJK), Dana 30 Front (D30-488RJK), Dana 44 Rear (D44-488JK), Dana 30, Dana 44, Dana 44, Dana 30 JK Reverse |
| Emission Code | Legal US |
| Front Differential Carrier | Open case 3.37 and up |
| Front Differential Carrier Break | Open case 3.73 and up |
| Gear Ratio | 4.88, 4.88 |
| Harmonized Tariff Code (Schedule B) | 8708990011 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | B |
| Pinion Gear Tooth Quantity | 8, 8 |
| Pinion Shaft Diameter | 1.376, 1.376 |
| Pinion Spline Count | 24, 24 |
| Position | Front Or Rear, Front and Rear |
| Ratio | 4.88 |
| Ring and Pinion Gear Ratio | 4.88 |
| Ring Gear Bolt Quantity | 10, 10 |
| Ring Gear Diameter | 7.12 Front (D30-488RJK), 7.12 Front (D30-488RJK), 8.5 Rear (D44-488JK) |
| Ring Gear Material | 8620 Steel, 8620 Steel |
| Ring Gear Outside Diameter | 7.12 Front (D30-488RJK), 8.5 Rear (D44-488JK) |
| Ring Gear Rotation | Reverse Front (D30-488RJK), Reverse Front (D30-488RJK), Standard Rear (D44-488JK), Reverse Front (D30-488RJK) |
| Ring Gear Tooth Quantity | 39, 39 |
| SDR Required Flag | N |
| Taxonomy | Differential LD |
| Taxonomy A | LD Differential, LD Differential |
| Taxonomy B | Ring and Pinion Gear Packages, Ring and Pinion Gear Packages |
| Taxonomy C | Front and Rear, Front and Rear |
| Taxonomy D | 4.88, 4.88 |
| Warranty Time | 12 |
| GTIN | 00698231945100 |
